Industrial Portable Screw Type Compressor 13.0m3/Min 75dB 75kw

  • Industrial Portable Screw Type Compressor 13.0m3/Min 75dB 75kw
  • Industrial Portable Screw Type Compressor 13.0m3/Min 75dB 75kw
  • Industrial Portable Screw Type Compressor 13.0m3/Min 75dB 75kw
Place of Origin CHINA
Brand Name OEM
Certification CE
Model Number CHIC-50A
Minimum Order Quantity 500
Price USD 40-45
Packaging Details packing size(L×W×H)：1300mm×850mm×1210mm
Delivery Time 7days
Supply Ability 500Pcs/Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name 75kw 100hp CHIC-100A Direct Driven Used Rotary Screw Air Compressor Air Delivery 13.0m³/min
Electricity Three Phase 380/60 Or 440/60 (V//Hz) Pressure 8Bar
Noise Level 75±2dB Power 100HP/75KW
N.weigh 1500KGS Color Blue
Highlight

75kw Portable Screw Type Compressor

,

100HP Portable Rotary Air Compressor

,

13.0m3/Min Screw Air Compressor
Leave a Message
Product Description

75kw Portable Screw Compressor Industrial 13.0m3 Min 75dB



High efficirency and learge air volume , greatly lower the temperature , prolong the lubricating oil change period

EXHAUST

The exhqaust from the com-pressor is directly discharged to the tank which reduces the intermediate connecting pipe and effectively saves space

High performance frequency converter

Makes the operation more stable and carrying out real-time vetor calculation according to different air delivery

PLC

Industrial Portable Screw Type Compressor 13.0m3/Min 75dB 75kw 0













Technical parameters



Model CHIC-100A
Power 100HP/75KW
FAD: (M3/MIN) 13.0
Pressure 8 bar
Cooling Air-cooling
Lubricant 36L
Noise level 68±2dB
Drive method Direct drive type
Discharge temperature Environment Temp+15℃-18℃
Electricity Three phase 220/60 or 440/60 (V//Hz)
Starting method Y-△ starter
Air outlet: Pipe diameter(inch)

G2″
Oil content of air <2ppm
Dimension 1150MM*1550MM*1660MM
Net weight 1500KGS



Packaging & Shipping



Packaging Details
Standard export carton or plywood case 1pcs/box
Port
Shanghai/Ningbo



Industrial Portable Screw Type Compressor 13.0m3/Min 75dB 75kw 1

Our services



1.We promise to reply your inquiry relational our product within 24hours.

2.OEM&ODM service for your unique idea with absolutely convenient.

3.Experienced foreign trader with professional product knowledge.

4.Value on business credite , promise to protect your sales data, design,patent information.

5. Sample & OEM service is available

6. After-sales service. any question will be settled within 3 days



FAQ



Q1. Are you a factory?
A. Yes, We are professional air compressor factory with more than 10 years experience.

Q2. How can i get a quotation?
A. Leave us message with your purchase requemets and we will reply you within one hour on working time. And you may contact us directly by Trade Manager

Q3. How many design do you have? How can i get your catalog?
A. We have hundreds of advanced design for your choice , And we have new design every year. Just tell us what kind of product you need and we will provide you plenty of choice,

Q4. How about your price?
A. Send me details about what you need, you will get the best price in China. The price is competitive over the world.

Q5. What's the delivery time and what's the package?
A. Normally the delivery time is about 25-35 days, Al our products are packed with sea worthy package.
